Drillhole Details

SA Geodata Database - Drillhole Details

Drillhole:

16697

Drillhole Name:

PRICES BORE 1

Details LocationStratigraphyLithologyPetrophysics Core Details Spectral Scanning Rock Samples Historical Documents References

Representative Drillhole From a Larger Program

Drillhole Program Comments

Map / Unit Number

613700054

Max Drilled Depth (m)

499.5

Max Drilled Date

27/10/1978

Cored Length

451.5

Tenement

EL 333

Operator

Kennecott Exploration (Australia) Pty Ltd.

Target

Gold, Copper, Uranium

General Comments

DOWNHOLE LOGGING BY SADME;FOUNDRY SAND INVEST: RB80/94Sample method = Cored.Detailed Geol. Log

Dip

-90

Azimuth

Class

Mineral Water Well Petroleum Engineering Stratigraphy

Datum

GDA2020

Coordinate Source

MGA Easting

612785.45

MGA Northing

6658607.28

MGA Zone

Long Degrees

136

Long Minutes

Long Seconds

18.108

S Lat Degrees

S Lat Minutes

S Lat Seconds

55.623

Long Degrees Decimal

136.1716968

Lat Degrees Decimal

-30.1987843

Horizontal Accuracy

Map 250K

SH5311 KINGOONYA

Map 100K

6137 Parakylia

Map 50K

SA Geodata - Database Reference

Site No

321498

Metres From

Metres To

Map Symbol

Major Lithology

Minor Lithology

Description

Tmw

SAND

Unconsolidated, mature, well-sorted, non-calcareous quartz sand.

Strat Unit Name

Watchie Sandstone

Strat Unit Description

Basal conglomerate, sand lenses, lower fine-grained sand, upward coarsening sand on top. Regressive lacustrine.

GIS Code

m----w

CP-b

CLAYSTONE

Brown claystones.

Strat Unit Name

Boorthanna Formation

Strat Unit Description

Diamictite with shale intercalations in the basal unit, the upper unit with rhythmically bedded coarse and fine-grained clastics. Subaqueous deposition of glacial debris transported as mud flows.

GIS Code

CP---b

118

Erha

DOLOMITIC LIMESTONE

MUDSTONE

Massive grey dolomitic limestone and mudstone, intraformational mud clast/limestone breccia and conglomerate. Minor red-brown shale, oolitic dolostone and microbialite/stromatolite in basal part.

Strat Unit Name

Andamooka Limestone

Strat Unit Description

Limestone, grey, off-white, brown, buff, pink, recrystallised, commonly dolomitised, locally sandy or pyritic. Intraclastic or oolitic interbeds; siliciclastics at base. Local trilobite fragments, archaeocyatha, calcimicrobes. Peritidal/subtidal shelf.

GIS Code

E-rh-a

118

140.64

Nhwsts

SANDSTONE

SILTSTONE

Fine-grained quartzitic sandstone and minor siltstone intercalations.

Strat Unit Name

Simmens Quartzite Member

Strat Unit Description

Quartzite, blocky; sandstone, cream.

GIS Code

N-hwsts

140.64

350

Nhwstt

SHALE

SANDSTONE

Red-brown laminated shale and fine-grained sandstone.

Strat Unit Name

Tregolana Shale Member

Strat Unit Description

Shale, red and green; siltstone.

GIS Code

N-hwstt

350

363.42

Nhwsn

SHALE

DOLOMITE ROCK

Red-brown shale with thin grey dolomite layers.

Strat Unit Name

Nuccaleena Formation

Strat Unit Description

Dolomite, thin, laminated, micritic, with interbedded shale near the top.

GIS Code

N-hwsn

363.42

363.6

? MN

CONGLOMERATE

White quartz pebble conglomerate. Part of Neoproterozoic Adelaidean or Mesoproterozoic Pandurra Formation?

Strat Unit Name

Mesoproterozoic-Neoproterozoic rocks

Strat Unit Description

Undifferentiated Meso-Neoproterozoic rocks.

GIS Code

363.6

499.45

M-p

SANDSTONE

SILTSTONE

Red-brown medium- to coarse-grained, pebbly sandstone with minor siltstone intercalations.

Strat Unit Name

Pandurra Formation

Strat Unit Description

Sandstone, quartz and lithic, m.g.-c.g., poorly sorted; sandstone, well-sorted, v.f.g.-m.g.; conglomerate, granule to pebble; mudstone; siltstone. Red, brown or purple with reduction spotting or mottling. Fluvial, large-scale cross-bedding and liesegang banding. Maximum deposition 1424±51 Ma (Rb-Sr).

GIS Code

M----p

	Qualifications	Organisation	Date	Metres From	Metres To
Select	Geologist	Office of Minerals & Energy Resourc	20/03/2019	0	499.45

Sample Allowed Hazard

Metres From	Metres To	Feet From	Feet To	Core Group	Library Location	Culled	Core Previously Inspected	Sample Record	Sample Returned to Library
0.00	48.00	0.00	157.48	Cutting	Tonsley	N	Y	Y	N
48.00	53.00	157.48	173.88	Core	Tonsley	N	Y	N	N
53.00	58.00	173.88	190.29	Core	Tonsley	N	Y	N	N
58.00	63.30	190.29	207.68	Core	Tonsley	N	Y	N	N
63.30	68.30	207.68	224.08	Core	Tonsley	N	Y	N	N
68.30	72.90	224.08	239.17	Core	Tonsley	N	Y	N	N
72.90	77.80	239.17	255.25	Core	Tonsley	N	Y	N	N
77.80	82.40	255.25	270.34	Core	Tonsley	N	Y	N	N
82.40	87.40	270.34	286.75	Core	Tonsley	N	Y	N	N
87.40	92.00	286.75	301.84	Core	Tonsley	N	Y	N	N
92.00	96.80	301.84	317.59	Core	Tonsley	N	Y	N	N
96.80	101.80	317.59	333.99	Core	Tonsley	N	Y	N	N
101.80	106.60	333.99	349.74	Core	Tonsley	N	Y	N	N
106.60	112.10	349.74	367.78	Core	Tonsley	N	Y	N	N
112.10	116.70	367.78	382.87	Core	Tonsley	N	Y	N	N
116.70	121.40	382.87	398.29	Core	Tonsley	N	Y	N	N
121.40	126.40	398.29	414.70	Core	Tonsley	N	Y	N	N
126.40	131.30	414.70	430.77	Core	Tonsley	N	Y	N	N
131.30	136.10	430.77	446.52	Core	Tonsley	N	Y	N	N
136.10	141.00	446.52	462.60	Core	Tonsley	N	Y	N	N
141.00	146.00	462.60	479.00	Core	Tonsley	N	Y	N	N
146.00	150.80	479.00	494.75	Core	Tonsley	N	Y	N	N
150.80	155.70	494.75	510.83	Core	Tonsley	N	Y	N	N
155.70	160.70	510.83	527.23	Core	Tonsley	N	Y	N	N
160.70	165.80	527.23	543.96	Core	Tonsley	N	Y	N	N
165.80	170.70	543.96	560.04	Core	Tonsley	N	Y	N	N
170.70	175.70	560.04	576.44	Core	Tonsley	N	Y	N	N
175.70	180.60	576.44	592.52	Core	Tonsley	N	Y	N	N
180.60	185.50	592.52	608.60	Core	Tonsley	N	Y	N	N
185.50	190.40	608.60	624.67	Core	Tonsley	N	Y	N	N
190.40	195.20	624.67	640.42	Core	Tonsley	N	Y	N	N
195.20	200.10	640.42	656.50	Core	Tonsley	N	Y	N	N
200.10	202.40	656.50	664.04	Core	Tonsley	N	Y	N	N
202.40	213.90	664.04	701.77	Core	Tonsley	N	Y	N	N
213.90	221.00	701.77	725.07	Core	Tonsley	N	Y	N	N
221.00	228.10	725.07	748.36	Core	Tonsley	N	Y	N	N
228.10	235.20	748.36	771.65	Core	Tonsley	N	Y	N	N
235.20	242.20	771.65	794.62	Core	Tonsley	N	Y	N	N
242.20	249.20	794.62	817.59	Core	Tonsley	N	Y	N	N
249.20	256.30	817.59	840.88	Core	Tonsley	N	Y	N	N
256.30	263.30	840.88	863.85	Core	Tonsley	N	Y	N	N
263.30	270.30	863.85	886.81	Core	Tonsley	N	Y	N	N
270.30	277.20	886.81	909.45	Core	Tonsley	N	Y	N	N
277.20	284.30	909.45	932.74	Core	Tonsley	N	Y	N	N
284.30	291.60	932.74	956.69	Core	Tonsley	N	Y	N	N
291.60	298.60	956.69	979.66	Core	Tonsley	N	Y	N	N
298.60	305.60	979.66	1002.62	Core	Tonsley	N	Y	N	N
305.60	312.60	1002.62	1025.59	Core	Tonsley	N	Y	N	N
312.60	319.80	1025.59	1049.21	Core	Tonsley	N	Y	N	N
319.80	326.80	1049.21	1072.18	Core	Tonsley	N	Y	N	N
326.80	333.30	1072.18	1093.50	Core	Tonsley	N	Y	N	N
333.30	340.80	1093.50	1118.11	Core	Tonsley	N	Y	N	N
340.80	347.90	1118.11	1141.40	Core	Tonsley	N	Y	N	N
347.90	354.80	1141.40	1164.04	Core	Tonsley	N	Y	N	N
354.80	362.00	1164.04	1187.66	Core	Tonsley	N	Y	N	N
362.00	369.10	1187.66	1210.96	Core	Tonsley	N	Y	N	N
369.10	376.00	1210.96	1233.60	Core	Tonsley	N	Y	N	N
376.00	382.90	1233.60	1256.23	Core	Tonsley	N	Y	N	N
382.90	390.90	1256.23	1282.48	Core	Tonsley	N	Y	N	N
390.90	397.40	1282.48	1303.81	Core	Tonsley	N	Y	N	N
397.40	405.00	1303.81	1328.74	Core	Tonsley	N	Y	N	N
405.00	412.00	1328.74	1351.71	Core	Tonsley	N	Y	N	N
412.00	419.00	1351.71	1374.67	Core	Tonsley	N	Y	N	N
419.00	426.00	1374.67	1397.64	Core	Tonsley	N	Y	N	N
426.00	433.10	1397.64	1420.93	Core	Tonsley	N	Y	N	N
433.10	440.00	1420.93	1443.57	Core	Tonsley	N	Y	Y	N
440.00	447.00	1443.57	1466.54	Core	Tonsley	N	Y	N	N
447.00	454.10	1466.54	1489.83	Core	Tonsley	N	Y	N	N
454.10	461.00	1489.83	1512.47	Core	Tonsley	N	Y	N	N
461.00	468.00	1512.47	1535.43	Core	Tonsley	N	Y	N	N
468.00	475.00	1535.43	1558.40	Core	Tonsley	N	Y	N	N
475.00	482.00	1558.40	1581.36	Core	Tonsley	N	Y	N	N
482.00	489.90	1581.36	1607.28	Core	Tonsley	N	Y	N	N
489.90	496.90	1607.28	1630.25	Core	Tonsley	N	Y	N	N
496.90	499.40	1630.25	1638.45	Core	Tonsley	N	Y	N	N

Metres From	Metres To	PDF Summary Images
48	499.4	16697_Prices_Bore1_cs.pdf (325 KB)	Request information about NVCL data

Downloads

Download Type:
Spectral Geologist (TSG) data file

TSG viewer is required to view the downloaded TSG files. The following link is a suggested free viewer: https://research.csiro.au/thespectralgeologist/

Enter an email address for tracking the status of the download request.
Email address*:

Scalars

List of Scalars:

Plots

Summary Mineral Plots

Shortwave Infrared

Thermal Infrared

Overview Scalar Plot

Individual Scalar Plots

Scalar Code Here

Binning (Smoothing)
