Qualifications	Organisation	Date	Metres From	Metres To	Insturment Type	Measure Method
Geologist	DMITRE	18/02/2014	140.2	170	Exploranium Kappameter KT-9 (Magsus Meter)

Metres From	Metres To	Type	Value	Unit
140.2	140.2	Magnetic Susceptibility	0.000010	SI units magnetic susceptibility
142.6	142.6	Magnetic Susceptibility	0.000030	SI units magnetic susceptibility
145	145	Magnetic Susceptibility	0.000010	SI units magnetic susceptibility
149	149	Magnetic Susceptibility	0.000040	SI units magnetic susceptibility
153	153	Magnetic Susceptibility	0.000020	SI units magnetic susceptibility
156	156	Magnetic Susceptibility	0.000010	SI units magnetic susceptibility
160.3	160.3	Magnetic Susceptibility	0.000410	SI units magnetic susceptibility
162.75	162.75	Magnetic Susceptibility	0.000450	SI units magnetic susceptibility
165.2	165.2	Magnetic Susceptibility	0.000320	SI units magnetic susceptibility
167.6	167.6	Magnetic Susceptibility	0.0001	SI units magnetic susceptibility
170	170	Magnetic Susceptibility	0.000230	SI units magnetic susceptibility

Qualifications	Organisation	Date	Metres From	Metres To	Insturment Type	Measure Method
Geologist	DMITRE	17/02/2014	140.2	170

Metres From	Metres To	Type	Value	Unit
140.2	140.2	Specific Gravity (density)	2.15	Dimensionless numeric value
142.6	142.6	Specific Gravity (density)	2.05	Dimensionless numeric value
145	145	Specific Gravity (density)	2.01	Dimensionless numeric value
149	149	Specific Gravity (density)	2.58	Dimensionless numeric value
153	153	Specific Gravity (density)	2.55	Dimensionless numeric value
156	156	Specific Gravity (density)	2.38	Dimensionless numeric value
160.3	160.3	Specific Gravity (density)	3.11	Dimensionless numeric value
162.75	162.75	Specific Gravity (density)	3.11	Dimensionless numeric value
165.2	165.2	Specific Gravity (density)	3.07	Dimensionless numeric value
167.6	167.6	Specific Gravity (density)	3	Dimensionless numeric value
170	170	Specific Gravity (density)	2.96	Dimensionless numeric value

Metres From	Metres To	Feet From	Feet To	Core Group	Library Location	Culled	Core Previously Inspected	Sample Record	Sample Returned to Library
0.00	96.00	0.00	314.96	Cutting	Tonsley	N	Y	Y	N
96.00	101.00	314.96	331.36	Core	Tonsley	N	Y	N	N
101.00	106.00	331.36	347.77	Core	Tonsley	N	Y	N	N
106.00	111.00	347.77	364.17	Core	Tonsley	N	Y	N	N
111.00	116.00	364.17	380.58	Core	Tonsley	N	Y	N	N
116.00	121.00	380.58	396.98	Core	Tonsley	N	Y	N	N
121.00	126.00	396.98	413.39	Core	Tonsley	N	Y	N	N
126.00	130.60	413.39	428.48	Core	Tonsley	N	Y	Y	N
130.60	135.30	428.48	443.90	Core	Tonsley	N	Y	N	N
135.30	140.20	443.90	459.97	Core	Tonsley	N	Y	N	N
140.20	145.00	459.97	475.72	Core	Tonsley	N	Y	Y	Y
145.00	153.00	475.72	501.97	Core	Tonsley	N	Y	N	N
153.00	160.30	501.97	525.92	Core	Tonsley	N	Y	Y	Y
160.30	165.20	525.92	541.99	Core	Tonsley	N	Y	Y	Y
165.20	170.00	541.99	557.74	Core	Tonsley	N	Y	Y	Y
170.00	171.00	557.74	561.02	Core	Tonsley	N	Y	Y	Y

Overview Scalar Plot

Individual Scalar Plots

Scroll down the page to view individual scalar plots Tip: To change the depth display on the overview scaler plot, hover the mouse over the graphs light blue handles, located on the left or right of the overview graph. When over the handle, the mouse pointer displays a double arrow. Clicking on and dragging the handle inwards will alter the depth display in all individual scalar plots below.

Tip: The scalar plot legend is interactive, you can mouse click a legend item to customise the plot display. To change the legend, simply use the mouse to drag and drop legend items in the preferred order. Reordering the legend will effect the order of elements displayed in the graph Tip: To display a sample count of meters, simply hover the mouse pointer over the graph.

Sample Number	Depth From	Depth To	Sample Source	Collected By	Date Collected
52822	54	63	Drill cuttings	PAL	13/10/1987
52813	130.33		Drill core	FLINT, R.B.	26/10/1978
2018283	141	142	Sawn quarter drill core	FABRIS, A.J.	15/10/2013
52821	142.45		Drill core	PAL	18/02/1986
52814	143.25		Drill core	FLINT, R.B.	26/10/1978
2018282	156.75	157.75	A full face slice of core	FABRIS, A.J.	15/10/2013
81185	158	168	Drill core	DAMPIER MINING CO LTD.
2018281	160	161	A full face slice of core	FABRIS, A.J.	15/10/2013
630322	164.7	164.8	Drill core	TEALE, G.S.	25/08/2003
2018280	170	171	A full face slice of core	FABRIS, A.J.	15/10/2013
630323	170.7	170.9	Drill core	TEALE, G.S.	25/08/2003
52815				FLINT, R.B.
52816				FLINT, R.B.

Document	Document ID	Information Type	Document Details	Reports Database
Envelope	03017	Geochemistry Ref.	Wright, R.G. Progress reports, EL 304, Danae Hill, South Australia. Newmont-Dampier Joint Venture. South Australia. Department of Primary Industries and Resources. Open file Envelope 1978	SAMREF
Envelope	03017	Geological Log Ref.	Wright, R.G. Progress reports, EL 304, Danae Hill, South Australia. Newmont-Dampier Joint Venture. South Australia. Department of Primary Industries and Resources. Open file Envelope 1978	SAMREF
Envelope	03031	Master Ref.	Wright, R.G. Progress and final reports, EL 305 The Twins, SA. South Australia. Department of Primary Industries and Resources. Open file Envelope 1978	SAMREF
Envelope	03017	Petrology Ref.	Wright, R.G. Progress reports, EL 304, Danae Hill, South Australia. Newmont-Dampier Joint Venture. South Australia. Department of Primary Industries and Resources. Open file Envelope 1978	SAMREF
