Drillhole:

14057

Drillhole Name:

DP-1

Details LocationStratigraphyLithologyPetrophysics Core Details Spectral Scanning Rock Samples Historical Documents References

Representative Drillhole From a Larger Program

Drillhole Program Comments

Map / Unit Number

603700145

Max Drilled Depth (m)

616.6

Max Drilled Date

01/01/1981

Cored Length

Tenement

EL 600

Operator

Esso Minerals Pty Ltd.

Target

Gold, Copper, Uranium

General Comments

GEOCHR G7914/89;G.S.A.ABSTR,25:110-111;PERCUSSION TO 258MSample method = Part Cored.Detailed Geol. Log

Dip

-90

Azimuth

Class

Mineral Water Well Petroleum Engineering Stratigraphy

Datum

GDA2020

Coordinate Source

GPS Averaged Position

MGA Easting

581259.77

MGA Northing

6679395.51

MGA Zone

Long Degrees

135

Long Minutes

Long Seconds

33.459

S Lat Degrees

S Lat Minutes

S Lat Seconds

49.39

Long Degrees Decimal

135.8426276

Lat Degrees Decimal

-30.0137195

Horizontal Accuracy

Map 250K

SH5311 KINGOONYA

Map 100K

6037 Eba

Map 50K

SA Geodata - Database Reference

Site No

11751

Metres From

Metres To

Map Symbol

Major Lithology

Minor Lithology

Description

Krmb

CLAYSTONE

SANDSTONE

Claystone, shale and ferruginous sandstone. Probably includes Bulldog Shale and Cadna-owie Formation.

Strat Unit Name

Bulldog Shale

Strat Unit Description

Mudstone, grey, bioturbated, marine fossiliferous and shaly; minor silt to very fine-grained sandstone intervals, limestone, or concretion horizons. Contains shell and plant fragments, glendonites, lonestones and pyrite. Deposited in early Aptian (c. 125Ma) to mid –Albian (c. 100Ma)

GIS Code

K--rmb

126

? P-s

SHALE

CLAYSTONE

Shale and claystone.

Strat Unit Name

Stuart Range Formation

Strat Unit Description

Shale, homogenous marine, with minor siltstone and sandstone. Deposited in a quiet water restricted marine environment.

GIS Code

P----s

126

166

CP-b

SANDSTONE

CONGLOMERATE

Sandstone to fine siltstone; basal conglomerate.

Strat Unit Name

Boorthanna Formation

Strat Unit Description

Diamictite with shale intercalations in the basal unit, the upper unit with rhythmically bedded coarse and fine-grained clastics. Subaqueous deposition of glacial debris transported as mud flows.

GIS Code

CP---b

166

616.6

AYm-d

METARHYODACITE

METABASALT

Bimodal (rhyolite-dacite and andesite-basalt) low-grade (lower-middle greenschist facies) meta-volcanics and meta-volcaniclastics, schistose to undeformed, strongly altered.

Strat Unit Name

Devils Playground Volcanics

Strat Unit Description

Basalt to andesite, green-grey, lava, breccia, tuff, often porphyritic; rhyodacite, pink-grey, lava, tuff, occasionally porphyritic or spherulitic. Greenschist facies, moderate variable foliation. U-Pb age 2558+/-6Ma.

GIS Code

AYm--d

	Qualifications	Organisation	Date	Metres From	Metres To
Select	Geologist	Office of Minerals & Energy Resourc	19/02/2019	0	616.60

Qualifications	Organisation	Date	Metres From	Metres To	Insturment Type	Measure Method
Geologist	DMITRE	17/02/2014	258	615

Metres From	Metres To	Type	Value	Unit
258	258	Specific Gravity (density)	2.68	Dimensionless numeric value
261.3	261.3	Specific Gravity (density)	2.69	Dimensionless numeric value
264	264	Specific Gravity (density)	2.67	Dimensionless numeric value
265.2	265.2	Specific Gravity (density)	2.71	Dimensionless numeric value
269.5	269.5	Specific Gravity (density)	2.72	Dimensionless numeric value
274.3	274.3	Specific Gravity (density)	2.66	Dimensionless numeric value
276	276	Specific Gravity (density)	2.70	Dimensionless numeric value
278.3	278.3	Specific Gravity (density)	2.68	Dimensionless numeric value
282.5	282.5	Specific Gravity (density)	2.67	Dimensionless numeric value
286.7	286.7	Specific Gravity (density)	2.67	Dimensionless numeric value
291.2	291.2	Specific Gravity (density)	2.66	Dimensionless numeric value
295.8	295.8	Specific Gravity (density)	2.67	Dimensionless numeric value
299.6	299.6	Specific Gravity (density)	2.71	Dimensionless numeric value
303.5	303.5	Specific Gravity (density)	2.69	Dimensionless numeric value
307	307	Specific Gravity (density)	2.64	Dimensionless numeric value
309.9	309.9	Specific Gravity (density)	2.61	Dimensionless numeric value
313.4	313.4	Specific Gravity (density)	2.68	Dimensionless numeric value
317.2	317.2	Specific Gravity (density)	2.71	Dimensionless numeric value
321.7	321.7	Specific Gravity (density)	2.72	Dimensionless numeric value
325	325	Specific Gravity (density)	2.68	Dimensionless numeric value
326.2	326.2	Specific Gravity (density)	2.70	Dimensionless numeric value
331.3	331.3	Specific Gravity (density)	2.67	Dimensionless numeric value
334	334	Specific Gravity (density)	2.71	Dimensionless numeric value
337.1	337.1	Specific Gravity (density)	2.73	Dimensionless numeric value
341.5	341.5	Specific Gravity (density)	2.71	Dimensionless numeric value
346.5	346.5	Specific Gravity (density)	2.79	Dimensionless numeric value
351	351	Specific Gravity (density)	2.75	Dimensionless numeric value
354	354	Specific Gravity (density)	2.69	Dimensionless numeric value
356.1	356.1	Specific Gravity (density)	2.71	Dimensionless numeric value
360.4	360.4	Specific Gravity (density)	2.68	Dimensionless numeric value
362	362	Specific Gravity (density)	2.68	Dimensionless numeric value
365.1	365.1	Specific Gravity (density)	2.72	Dimensionless numeric value
370	370	Specific Gravity (density)	2.70	Dimensionless numeric value
375.5	375.5	Specific Gravity (density)	2.65	Dimensionless numeric value
380.2	380.2	Specific Gravity (density)	2.67	Dimensionless numeric value
384	384	Specific Gravity (density)	2.67	Dimensionless numeric value
385	385	Specific Gravity (density)	2.68	Dimensionless numeric value
389.7	389.7	Specific Gravity (density)	2.68	Dimensionless numeric value
394.5	394.5	Specific Gravity (density)	2.69	Dimensionless numeric value
395	395	Specific Gravity (density)	2.66	Dimensionless numeric value
399.1	399.1	Specific Gravity (density)	2.69	Dimensionless numeric value
403.9	403.9	Specific Gravity (density)	2.71	Dimensionless numeric value
408.2	408.2	Specific Gravity (density)	2.72	Dimensionless numeric value
413	413	Specific Gravity (density)	2.71	Dimensionless numeric value
414	414	Specific Gravity (density)	2.70	Dimensionless numeric value
417.5	417.5	Specific Gravity (density)	2.71	Dimensionless numeric value
422.5	422.5	Specific Gravity (density)	2.66	Dimensionless numeric value
425	425	Specific Gravity (density)	2.80	Dimensionless numeric value
427.8	427.8	Specific Gravity (density)	2.71	Dimensionless numeric value
432.1	432.1	Specific Gravity (density)	2.72	Dimensionless numeric value
435	435	Specific Gravity (density)	2.76	Dimensionless numeric value
436.7	436.7	Specific Gravity (density)	2.70	Dimensionless numeric value
441.6	441.6	Specific Gravity (density)	2.71	Dimensionless numeric value
446	446	Specific Gravity (density)	2.78	Dimensionless numeric value
446.2	446.2	Specific Gravity (density)	2.76	Dimensionless numeric value
451.2	451.2	Specific Gravity (density)	2.70	Dimensionless numeric value
455.8	455.8	Specific Gravity (density)	2.68	Dimensionless numeric value
456	456	Specific Gravity (density)	2.73	Dimensionless numeric value
461.6	461.6	Specific Gravity (density)	2.71	Dimensionless numeric value
466.5	466.5	Specific Gravity (density)	2.71	Dimensionless numeric value
470.3	470.3	Specific Gravity (density)	2.74	Dimensionless numeric value
475	475	Specific Gravity (density)	2.80	Dimensionless numeric value
475	475	Specific Gravity (density)	2.76	Dimensionless numeric value
479.6	479.6	Specific Gravity (density)	2.80	Dimensionless numeric value
484.41	484.41	Specific Gravity (density)	2.73	Dimensionless numeric value
489.1	489.1	Specific Gravity (density)	2.71	Dimensionless numeric value
493.9	493.9	Specific Gravity (density)	2.68	Dimensionless numeric value
496	496	Specific Gravity (density)	2.67	Dimensionless numeric value
499.2	499.2	Specific Gravity (density)	2.71	Dimensionless numeric value
503.5	503.5	Specific Gravity (density)	2.72	Dimensionless numeric value
504	504	Specific Gravity (density)	2.72	Dimensionless numeric value
508.4	508.4	Specific Gravity (density)	2.73	Dimensionless numeric value
513.3	513.3	Specific Gravity (density)	2.77	Dimensionless numeric value
517	517	Specific Gravity (density)	2.76	Dimensionless numeric value
518.2	518.2	Specific Gravity (density)	2.71	Dimensionless numeric value
522.9	522.9	Specific Gravity (density)	2.75	Dimensionless numeric value
527.8	527.8	Specific Gravity (density)	2.74	Dimensionless numeric value
532.8	532.8	Specific Gravity (density)	2.73	Dimensionless numeric value
537	537	Specific Gravity (density)	2.79	Dimensionless numeric value
537.7	537.7	Specific Gravity (density)	2.72	Dimensionless numeric value
542.6	542.6	Specific Gravity (density)	2.70	Dimensionless numeric value
547.5	547.5	Specific Gravity (density)	2.66	Dimensionless numeric value
552.3	552.3	Specific Gravity (density)	2.86	Dimensionless numeric value
557.6	557.6	Specific Gravity (density)	2.76	Dimensionless numeric value
559	559	Specific Gravity (density)	2.80	Dimensionless numeric value
562.2	562.2	Specific Gravity (density)	2.82	Dimensionless numeric value
567.2	567.2	Specific Gravity (density)	2.79	Dimensionless numeric value
572	572	Specific Gravity (density)	2.82	Dimensionless numeric value
574	574	Specific Gravity (density)	2.78	Dimensionless numeric value
576.8	576.8	Specific Gravity (density)	2.77	Dimensionless numeric value
581.6	581.6	Specific Gravity (density)	2.77	Dimensionless numeric value
586.5	586.5	Specific Gravity (density)	2.82	Dimensionless numeric value
591.4	591.4	Specific Gravity (density)	2.68	Dimensionless numeric value
595	595	Specific Gravity (density)	2.69	Dimensionless numeric value
598.2	598.2	Specific Gravity (density)	2.82	Dimensionless numeric value
605	605	Specific Gravity (density)	2.86	Dimensionless numeric value
611.9	611.9	Specific Gravity (density)	2.75	Dimensionless numeric value
615	615	Specific Gravity (density)	2.70	Dimensionless numeric value

Qualifications	Organisation	Date	Metres From	Metres To	Insturment Type	Measure Method
Geologist	DMITRE	18/02/2014	258	615	Exploranium Kappameter KT-10 (Magsus Meter)

Metres From	Metres To	Type	Value	Unit
258	258	Magnetic Susceptibility	0.000341	SI units magnetic susceptibility
261.3	261.3	Magnetic Susceptibility	0.000401	SI units magnetic susceptibility
264	264	Magnetic Susceptibility	0.000249	SI units magnetic susceptibility
265.2	265.2	Magnetic Susceptibility	0.000346	SI units magnetic susceptibility
269.5	269.5	Magnetic Susceptibility	0.000427	SI units magnetic susceptibility
274.3	274.3	Magnetic Susceptibility	0.000306	SI units magnetic susceptibility
276	276	Magnetic Susceptibility	0.000297	SI units magnetic susceptibility
278.3	278.3	Magnetic Susceptibility	0.000343	SI units magnetic susceptibility
282.5	282.5	Magnetic Susceptibility	0.000292	SI units magnetic susceptibility
286.7	286.7	Magnetic Susceptibility	0.000327	SI units magnetic susceptibility
291.2	291.2	Magnetic Susceptibility	0.000273	SI units magnetic susceptibility
295.8	295.8	Magnetic Susceptibility	0.000251	SI units magnetic susceptibility
299.6	299.6	Magnetic Susceptibility	0.000534	SI units magnetic susceptibility
303.5	303.5	Magnetic Susceptibility	0.000313	SI units magnetic susceptibility
307	307	Magnetic Susceptibility	0.000346	SI units magnetic susceptibility
309.9	309.9	Magnetic Susceptibility	0.000343	SI units magnetic susceptibility
313.4	313.4	Magnetic Susceptibility	0.000327	SI units magnetic susceptibility
317.2	317.2	Magnetic Susceptibility	0.000316	SI units magnetic susceptibility
321.7	321.7	Magnetic Susceptibility	0.000598	SI units magnetic susceptibility
325	325	Magnetic Susceptibility	0.000565	SI units magnetic susceptibility
326.2	326.2	Magnetic Susceptibility	0.000534	SI units magnetic susceptibility
331.3	331.3	Magnetic Susceptibility	0.000514	SI units magnetic susceptibility
334	334	Magnetic Susceptibility	0.000392	SI units magnetic susceptibility
337.1	337.1	Magnetic Susceptibility	0.000516	SI units magnetic susceptibility
341.5	341.5	Magnetic Susceptibility	0.000431	SI units magnetic susceptibility
346.5	346.5	Magnetic Susceptibility	0.000454	SI units magnetic susceptibility
351	351	Magnetic Susceptibility	0.000567	SI units magnetic susceptibility
354	354	Magnetic Susceptibility	0.000586	SI units magnetic susceptibility
356.1	356.1	Magnetic Susceptibility	0.000553	SI units magnetic susceptibility
360.4	360.4	Magnetic Susceptibility	0.000622	SI units magnetic susceptibility
362	362	Magnetic Susceptibility	0.000688	SI units magnetic susceptibility
365.1	365.1	Magnetic Susceptibility	0.0006	SI units magnetic susceptibility
370	370	Magnetic Susceptibility	0.000667	SI units magnetic susceptibility
375.5	375.5	Magnetic Susceptibility	0.000291	SI units magnetic susceptibility
380.2	380.2	Magnetic Susceptibility	0.000506	SI units magnetic susceptibility
384	384	Magnetic Susceptibility	0.000684	SI units magnetic susceptibility
385	385	Magnetic Susceptibility	0.000474	SI units magnetic susceptibility
389.7	389.7	Magnetic Susceptibility	0.000703	SI units magnetic susceptibility
394.5	394.5	Magnetic Susceptibility	0.000587	SI units magnetic susceptibility
395	395	Magnetic Susceptibility	0.000588	SI units magnetic susceptibility
399.1	399.1	Magnetic Susceptibility	0.000655	SI units magnetic susceptibility
403.9	403.9	Magnetic Susceptibility	0.000557	SI units magnetic susceptibility
408.2	408.2	Magnetic Susceptibility	0.000580	SI units magnetic susceptibility
413	413	Magnetic Susceptibility	0.000449	SI units magnetic susceptibility
414	414	Magnetic Susceptibility	0.000506	SI units magnetic susceptibility
417.5	417.5	Magnetic Susceptibility	0.000429	SI units magnetic susceptibility
422.5	422.5	Magnetic Susceptibility	0.000574	SI units magnetic susceptibility
425	425	Magnetic Susceptibility	0.000632	SI units magnetic susceptibility
427.8	427.8	Magnetic Susceptibility	0.000556	SI units magnetic susceptibility
432.1	432.1	Magnetic Susceptibility	0.000641	SI units magnetic susceptibility
435	435	Magnetic Susceptibility	0.000824	SI units magnetic susceptibility
436.7	436.7	Magnetic Susceptibility	0.000694	SI units magnetic susceptibility
441.6	441.6	Magnetic Susceptibility	0.000625	SI units magnetic susceptibility
446	446	Magnetic Susceptibility	0.000850	SI units magnetic susceptibility
446.2	446.2	Magnetic Susceptibility	0.000802	SI units magnetic susceptibility
451.2	451.2	Magnetic Susceptibility	0.000554	SI units magnetic susceptibility
455.8	455.8	Magnetic Susceptibility	0.000564	SI units magnetic susceptibility
456	456	Magnetic Susceptibility	0.000586	SI units magnetic susceptibility
461.6	461.6	Magnetic Susceptibility	0.000455	SI units magnetic susceptibility
466.5	466.5	Magnetic Susceptibility	0.000467	SI units magnetic susceptibility
470.3	470.3	Magnetic Susceptibility	0.000417	SI units magnetic susceptibility
475	475	Magnetic Susceptibility	0.000430	SI units magnetic susceptibility
475	475	Magnetic Susceptibility	0.000379	SI units magnetic susceptibility
479.6	479.6	Magnetic Susceptibility	0.000545	SI units magnetic susceptibility
484.41	484.41	Magnetic Susceptibility	0.000549	SI units magnetic susceptibility
489.1	489.1	Magnetic Susceptibility	0.000562	SI units magnetic susceptibility
493.9	493.9	Magnetic Susceptibility	0.000424	SI units magnetic susceptibility
496	496	Magnetic Susceptibility	0.000529	SI units magnetic susceptibility
499.2	499.2	Magnetic Susceptibility	0.000488	SI units magnetic susceptibility
503.5	503.5	Magnetic Susceptibility	0.000367	SI units magnetic susceptibility
504	504	Magnetic Susceptibility	0.000275	SI units magnetic susceptibility
508.4	508.4	Magnetic Susceptibility	0.000279	SI units magnetic susceptibility
513.3	513.3	Magnetic Susceptibility	0.000632	SI units magnetic susceptibility
517	517	Magnetic Susceptibility	0.000543	SI units magnetic susceptibility
518.2	518.2	Magnetic Susceptibility	0.000630	SI units magnetic susceptibility
522.9	522.9	Magnetic Susceptibility	0.000591	SI units magnetic susceptibility
527.8	527.8	Magnetic Susceptibility	0.000588	SI units magnetic susceptibility
532.8	532.8	Magnetic Susceptibility	0.000558	SI units magnetic susceptibility
537	537	Magnetic Susceptibility	0.000533	SI units magnetic susceptibility
537.7	537.7	Magnetic Susceptibility	0.000612	SI units magnetic susceptibility
542.6	542.6	Magnetic Susceptibility	0.000499	SI units magnetic susceptibility
547.5	547.5	Magnetic Susceptibility	0.000395	SI units magnetic susceptibility
552.3	552.3	Magnetic Susceptibility	0.000348	SI units magnetic susceptibility
557.6	557.6	Magnetic Susceptibility	0.000544	SI units magnetic susceptibility
559	559	Magnetic Susceptibility	0.000529	SI units magnetic susceptibility
562.2	562.2	Magnetic Susceptibility	0.000488	SI units magnetic susceptibility
567.2	567.2	Magnetic Susceptibility	0.000689	SI units magnetic susceptibility
581.6	581.6	Magnetic Susceptibility	0.000648	SI units magnetic susceptibility
586.5	586.5	Magnetic Susceptibility	0.000450	SI units magnetic susceptibility
591.4	591.4	Magnetic Susceptibility	0.000124	SI units magnetic susceptibility
595	595	Magnetic Susceptibility	0.000380	SI units magnetic susceptibility
598.2	598.2	Magnetic Susceptibility	0.000461	SI units magnetic susceptibility
605	605	Magnetic Susceptibility	0.000504	SI units magnetic susceptibility
611.9	611.9	Magnetic Susceptibility	0.000496	SI units magnetic susceptibility
615	615	Magnetic Susceptibility	0.000419	SI units magnetic susceptibility
572	572	Magnetic Susceptibility	0.000597	SI units magnetic susceptibility
574	574	Magnetic Susceptibility	0.000384	SI units magnetic susceptibility
576.8	576.8	Magnetic Susceptibility	0.000577	SI units magnetic susceptibility

Sample Allowed Hazard

Metres From	Metres To	Feet From	Feet To	Core Group	Library Location	Culled	Core Previously Inspected	Sample Record	Sample Returned to Library
258.00	261.30	846.46	857.28	Core	Tonsley	N	Y	Y	N
261.30	265.20	857.28	870.08	Core	Tonsley	N	Y	Y	Y
265.20	269.50	870.08	884.19	Core	Tonsley	N	Y	N	N
269.50	274.30	884.19	899.93	Core	Tonsley	N	Y	Y	N
274.30	278.30	899.93	913.06	Core	Tonsley	N	Y	Y	Y
278.30	282.50	913.06	926.84	Core	Tonsley	N	Y	N	N
282.50	286.70	926.84	940.62	Core	Tonsley	N	Y	N	N
286.70	291.20	940.62	955.38	Core	Tonsley	N	Y	Y	N
291.20	295.80	955.38	970.47	Core	Tonsley	N	Y	N	N
295.80	299.60	970.47	982.94	Core	Tonsley	N	Y	N	N
299.60	303.50	982.94	995.73	Core	Tonsley	N	Y	Y	N
303.50	309.90	995.73	1016.73	Core	Tonsley	N	Y	Y	Y
309.90	313.40	1016.73	1028.22	Core	Tonsley	N	Y	N	N
313.40	317.20	1028.22	1040.68	Core	Tonsley	N	Y	Y	Y
317.20	321.70	1040.68	1055.45	Core	Tonsley	N	Y	Y	Y
321.70	326.20	1055.45	1070.21	Core	Tonsley	N	Y	Y	Y
326.20	331.30	1070.21	1086.94	Core	Tonsley	N	Y	N	N
331.30	337.10	1086.94	1105.97	Core	Tonsley	N	Y	Y	Y
337.10	341.50	1105.97	1120.41	Core	Tonsley	N	Y	Y	N
341.50	346.50	1120.41	1136.81	Core	Tonsley	N	Y	Y	N
346.50	351.00	1136.81	1151.57	Core	Tonsley	N	Y	N	N
351.00	356.10	1151.57	1168.31	Core	Tonsley	N	Y	Y	Y
356.10	360.40	1168.31	1182.41	Core	Tonsley	N	Y	Y	N
360.40	365.10	1182.41	1197.83	Core	Tonsley	N	Y	Y	Y
365.10	370.00	1197.83	1213.91	Core	Tonsley	N	Y	Y	N
370.00	375.50	1213.91	1231.96	Core	Tonsley	N	Y	Y	Y
375.50	380.20	1231.96	1247.38	Core	Tonsley	N	Y	Y	Y
380.20	385.00	1247.38	1263.12	Core	Tonsley	N	Y	Y	Y
385.00	389.70	1263.12	1278.54	Core	Tonsley	N	Y	Y	Y
389.70	394.50	1278.54	1294.29	Core	Tonsley	N	Y	Y	Y
394.50	399.10	1294.29	1309.38	Core	Tonsley	N	Y	Y	Y
399.10	403.90	1309.38	1325.13	Core	Tonsley	N	Y	N	N
403.90	408.20	1325.13	1339.24	Core	Tonsley	N	Y	Y	Y
408.20	413.00	1339.24	1354.99	Core	Tonsley	N	Y	N	N
413.00	417.50	1354.99	1369.75	Core	Tonsley	N	Y	Y	Y
417.50	422.50	1369.75	1386.15	Core	Tonsley	N	Y	N	N
422.50	427.80	1386.15	1403.54	Core	Tonsley	N	Y	Y	Y
427.80	432.10	1403.54	1417.65	Core	Tonsley	N	Y	N	N
432.10	436.70	1417.65	1432.74	Core	Tonsley	N	Y	Y	Y
436.70	441.50	1432.74	1448.49	Core	Tonsley	N	Y	N	N
441.50	446.20	1448.49	1463.91	Core	Tonsley	N	Y	Y	Y
446.20	451.20	1463.91	1480.31	Core	Tonsley	N	Y	Y	Y
451.20	455.80	1480.31	1495.41	Core	Tonsley	N	Y	Y	Y
455.80	461.60	1495.41	1514.44	Core	Tonsley	N	Y	Y	Y
461.60	465.50	1514.44	1527.23	Core	Tonsley	N	Y	N	N
465.50	470.30	1527.23	1542.98	Core	Tonsley	N	Y	N	N
470.30	475.00	1542.98	1558.40	Core	Tonsley	N	Y	Y	Y
475.00	479.60	1558.40	1573.49	Core	Tonsley	N	Y	Y	Y
479.60	484.10	1573.49	1588.25	Core	Tonsley	N	Y	Y	Y
484.10	489.10	1588.25	1604.66	Core	Tonsley	N	Y	N	N
489.10	493.90	1604.66	1620.41	Core	Tonsley	N	Y	N	N
493.90	499.20	1620.41	1637.80	Core	Tonsley	N	Y	Y	Y
499.20	503.50	1637.80	1651.90	Core	Tonsley	N	Y	Y	Y
503.50	508.40	1651.90	1667.98	Core	Tonsley	N	Y	Y	Y
508.40	513.30	1667.98	1684.06	Core	Tonsley	N	Y	N	N
513.30	518.20	1684.06	1700.13	Core	Tonsley	N	Y	Y	Y
518.20	522.90	1700.13	1715.55	Core	Tonsley	N	Y	Y	Y
522.90	527.80	1715.55	1731.63	Core	Tonsley	N	Y	Y	N
527.80	532.80	1731.63	1748.03	Core	Tonsley	N	Y	N	N
532.80	537.70	1748.03	1764.11	Core	Tonsley	N	Y	Y	Y
537.70	542.60	1764.11	1780.18	Core	Tonsley	N	Y	Y	Y
542.60	547.50	1780.18	1796.26	Core	Tonsley	N	Y	N	N
547.50	552.30	1796.26	1812.01	Core	Tonsley	N	Y	Y	N
552.30	557.60	1812.01	1829.40	Core	Tonsley	N	Y	N	N
557.60	562.20	1829.40	1844.49	Core	Tonsley	N	Y	Y	Y
562.20	567.20	1844.49	1860.89	Core	Tonsley	N	Y	N	N
567.20	572.00	1860.89	1876.64	Core	Tonsley	N	Y	Y	N
572.00	576.80	1876.64	1892.39	Core	Tonsley	N	Y	Y	Y
576.80	581.60	1892.39	1908.14	Core	Tonsley	N	Y	N	N
581.60	586.50	1908.14	1924.21	Core	Tonsley	N	Y	N	N
586.50	591.40	1924.21	1940.29	Core	Tonsley	N	Y	Y	Y
591.40	598.20	1940.29	1962.60	Core	Tonsley	N	Y	Y	Y
598.20	605.00	1962.60	1984.91	Core	Tonsley	N	Y	N	N
605.00	611.90	1984.91	2007.55	Core	Tonsley	N	Y	N	N
611.90	616.60	2007.55	2022.97	Core	Tonsley	N	Y	Y	Y

Metres From	Metres To	PDF Summary Images
258	616.6	14057_DP1_cs.pdf (394 KB)	Request information about NVCL data

Downloads

Download Type:

Spectral Geologist (TSG) data file

TSG viewer is required to view the downloaded TSG files. The following link is a suggested free viewer: https://research.csiro.au/thespectralgeologist/

Enter an email address for tracking the status of the download request.
Email address*: Email address is required

Options:

linescan

spectra

profilometer

traypics

mospic

mappics

Scalars

List of Scalars:

Plots

Summary Mineral Plots

Shortwave Infrared

Thermal Infrared

Scanned Core Imagery

Core Library Image

Sample Number	Depth From	Depth To	Sample Source	Collected By	Date Collected
13755	188	195	Drill core	GILES, C.W.	13/07/1989
13756	195	200	Drill core	GILES, C.W.	13/07/1989
13757	212	213	Drill core	GILES, C.W.	13/07/1989
13758	227	228	Drill core	GILES, C.W.	13/07/1989
13759	232	233	Drill core	GILES, C.W.	13/07/1989
13760	240	245	Drill core	GILES, C.W.	13/07/1989
13761	247	251	Drill core	GILES, C.W.	13/07/1989
13762	251	258	Drill core	GILES, C.W.	13/07/1989
2018255	263.8	264.8	Drill core	FABRIS, A.J.	9/10/2013
613117	264	264.1	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13763	264		Drill core	COWLEY, W.M.	20/11/1989
13741	271.8		Drill core	COWLEY, W.M.	12/01/1987
2733063	276	277	Pulp / powdered rock of known origin, typically a lab return	EXTERNAL - REFER CORE INSPECTION	10/05/2019
2018254	276	277	Drill core	FABRIS, A.J.	9/10/2013
13742	290.4		Drill core	COWLEY, W.M.	12/01/1987
13743	300.4		Drill core	COWLEY, W.M.	12/01/1987
13754	301.9		Drill core	DALY, S.J.	11/05/1989
2018253	307	308.2	Drill core	FABRIS, A.J.	9/10/2013
13744	314.4		Drill core	COWLEY, W.M.	12/01/1987
613118	318.8	318.9	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13764	318.9		Drill core	COWLEY, W.M.	20/11/1989
2018252	325.1	326.1	Drill core	FABRIS, A.J.	9/10/2013
2018251	334.1	335	Drill core	FABRIS, A.J.	9/10/2013
62776	341	342	Drill core	ESSO MINERALS PTY LTD.
613119	353.2	353.3	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13745	353.3		Drill core	COWLEY, W.M.	12/01/1987
2018250	354.1	355.1	Drill core	FABRIS, A.J.	9/10/2013
485743	357.1	357.2	Drill core	BREWER, A.M.	12/11/2001
2018249	362.3	363.2	Drill core	FABRIS, A.J.	9/10/2013
613120	368.6	368.7	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13751	368.6		Drill core	COWLEY, W.M.	1/02/1989
13765	368.7		Drill core	COWLEY, W.M.	20/11/1989
485742	373	373.1	Drill core	BREWER, A.M.	12/11/2001
13750	373.6	376.5	Drill core	COWLEY, W.M.	29/08/1988
613121	374	374.1	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13766	374.1		Drill core	COWLEY, W.M.	20/11/1989
13752	375.45		Drill core	COWLEY, W.M.	1/02/1989
13746	377.3		Drill core	COWLEY, W.M.	12/01/1987
613122	379.5	379.6	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13767	379.5		Drill core	COWLEY, W.M.	20/11/1989
13753	379.55		Drill core	COWLEY, W.M.	1/02/1989
1967789	380.2	382.6	A full face slice of core	REID, A.J.	28/11/2012
2018248	384	385	Drill core	FABRIS, A.J.	9/10/2013
2018247	394.5	395.4	Drill core	FABRIS, A.J.	9/10/2013
62775	404.3	405.4	Drill core	ESSO MINERALS PTY LTD.
613123	407.7	407.75	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13768	407.75		Drill core	COWLEY, W.M.	20/11/1989
2018246	414.1	415	Drill core	FABRIS, A.J.	9/10/2013
2018245	424.5	425.5	Drill core	FABRIS, A.J.	9/10/2013
1967790	424.9	425	A full face slice of core	REID, A.J.	28/11/2012
1967791	426.1	426.15	A full face slice of core	REID, A.J.	28/11/2012
2018244	435	435.7	Drill core	FABRIS, A.J.	9/10/2013
1967792	436.5	436.6	A full face slice of core	REID, A.J.	28/11/2012
2018243	446.2	447.1	Drill core	FABRIS, A.J.	9/10/2013
2018242	455.8	456.7	Drill core	FABRIS, A.J.	9/10/2013
2018241	475	475.9	Drill core	FABRIS, A.J.	9/10/2013
613124	480.5	480.6	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13769	480.6		Drill core	COWLEY, W.M.	20/11/1989
1967793	483.6	483.7	A full face slice of core	REID, A.J.	28/11/2012
2018240	495.4	496.5	Drill core	FABRIS, A.J.	9/10/2013
2018239	503.5	504.5	Drill core	FABRIS, A.J.	9/10/2013
13747	514.3		Drill core	COWLEY, W.M.	12/01/1987
2018238	517.2	518.2	Drill core	FABRIS, A.J.	9/10/2013
613125	523.2	523.3	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13770	523.2		Drill core	COWLEY, W.M.	20/11/1989
2018237	536.7	537.7	Drill core	FABRIS, A.J.	9/10/2013
1967794	551.3	551.4	A full face slice of core	REID, A.J.	28/11/2012
2018236	558.4	559.3	Drill core	FABRIS, A.J.	9/10/2013
13748	568.4		Drill core	COWLEY, W.M.	12/01/1987
62774	573.3	574.3	Drill core	ESSO MINERALS PTY LTD.
2018234	573.85	574.85	Drill core	FABRIS, A.J.	9/10/2013
613126	588.15	588.25	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13749	588.6		Drill core	COWLEY, W.M.	12/01/1987
2018233	595	596	Drill core	FABRIS, A.J.	9/10/2013
62773	612.9	614	Drill core	ESSO MINERALS PTY LTD.
2018232	615	616	Drill core	FABRIS, A.J.	9/10/2013
613127	616.3	616.4	Drill cuttings	EXTERNAL - REFER CORE INSPECTION	13/01/2003
13771	616.35		Drill core	COWLEY, W.M.	20/11/1989

Document	Document ID	Information Type	Document Details	Reports Database
MESA Journal	054	Geochronology Ref.	Reid, A.J.;Fricke, C.E.;Cowley, W.M. Extent of low-grade Archaean metavolcanics in the northeastern Gawler Craton: new evidence and definition of the Devils Playground Volcanics. MESA Journal 2009	SAMREF
Envelope	03784	Geochemistry Ref.	Herbison, I.;Greig, D.D.;Webb, R.J.;Watt, J.D.;Anderson, C.G.;Giles, C.W.;Robison, H.R.;Stracke, K.J.;Emslie, D.P.;Newell, B.H. Devils Playground; Mount Eba. Progress and relinquishment reports for the period 13/3/80 to 28/3/86. South Australia. Department of Primary Industries and Resources. Open file Envelope 1986	SAMREF
Envelope	03784	Master Ref.	Herbison, I.;Greig, D.D.;Webb, R.J.;Watt, J.D.;Anderson, C.G.;Giles, C.W.;Robison, H.R.;Stracke, K.J.;Emslie, D.P.;Newell, B.H. Devils Playground; Mount Eba. Progress and relinquishment reports for the period 13/3/80 to 28/3/86. South Australia. Department of Primary Industries and Resources. Open file Envelope 1986	SAMREF
Envelope	03784	Petrology Ref.	Herbison, I.;Greig, D.D.;Webb, R.J.;Watt, J.D.;Anderson, C.G.;Giles, C.W.;Robison, H.R.;Stracke, K.J.;Emslie, D.P.;Newell, B.H. Devils Playground; Mount Eba. Progress and relinquishment reports for the period 13/3/80 to 28/3/86. South Australia. Department of Primary Industries and Resources. Open file Envelope 1986	SAMREF
Envelope	03784	Geophysical Log(s)	Herbison, I.;Greig, D.D.;Webb, R.J.;Watt, J.D.;Anderson, C.G.;Giles, C.W.;Robison, H.R.;Stracke, K.J.;Emslie, D.P.;Newell, B.H. Devils Playground; Mount Eba. Progress and relinquishment reports for the period 13/3/80 to 28/3/86. South Australia. Department of Primary Industries and Resources. Open file Envelope 1986	SAMREF

Core Images

SA Geodata - Database Information Downloads

Explanation of the Stratigraphic Map Symbol and GIS code system

Overview Scalar Plot

Individual Scalar Plots

Scalar Code Here

Binning (Smoothing)
