Drillhole Details

Details LocationStratigraphyLithologyPetrophysics Core Details Spectral Scanning Rock Samples Historical Documents References

Representative Drillhole From a Larger Program

Drillhole Program Comments

Map / Unit Number

702900985

Max Drilled Depth (m)

1379.83

Max Drilled Date

28/11/1987

Cored Length

371

Tenement

PEL 16

Operator

International Mining Corporation NL.

Target

Gas, Oil

General Comments

PEL 16&0. Coordinate revised from 466805E 6225569N Z54

Dip

-90

Azimuth

Class

Mineral Water Well Petroleum Engineering Stratigraphy

Datum

GDA2020

Coordinate Source

GDA94 Transformed

MGA Easting

466805.55

MGA Northing

6225570.21

MGA Zone

Long Degrees

140

Long Minutes

Long Seconds

24.307

S Lat Degrees

S Lat Minutes

S Lat Seconds

36.606

Long Degrees Decimal

140.6400853

Lat Degrees Decimal

-34.1101683

Horizontal Accuracy

Map 250K

SI5410 RENMARK

Map 100K

7029 Renmark

Map 50K

SA Geodata - Database Reference

Site No

115645

Metres From

Metres To

Map Symbol

Major Lithology

Minor Lithology

Description

Kelly bushing to ground surface.

Strat Unit Name

no sample

Strat Unit Description

No sample: lost in drilling, cavity; sea if offshore.

GIS Code

------ns

20.4

? TpQlb

CLAY (UNDIFF. ORIGIN)

SAND

Clay (Claystone?), khaki-yellow-green-grey, firm, non-calcareous, trace fine quartz sand.

Strat Unit Name

Blanchetown Clay

Strat Unit Description

Clay, greenish grey, sandy; limestone, thin; and quartz sand; clay, green-grey, mottled, sandy.

GIS Code

pI--lb

20.4

58.5

Tpl

SANDSTONE

Sandstone, medium-very coarse grained, white-yellow-red.

Strat Unit Name

Loxton Sand

Strat Unit Description

Sand, glauconitic, micaceous and shelly gravel; Coarse-grained sand and fine gravel, and calcareous micaceous, medium to coarse-grained sandstone. Shallow marine, beach, aeolian, lacustrine and fluvial.

GIS Code

p----l

58.5

82.3

Tmpb

SANDSTONE

CLAYSTONE

Sandstone, coarse-very coarse grained, white-light grey, glauconitic, shell fragments, interbedded claystone, green/grey, firm, variably calcareous, minor glauconite.

Strat Unit Name

Bookpurnong Formation

Strat Unit Description

Marl; silty clay; minor fine-grained sand, glauconitic. Shallow marine.

GIS Code

mp---b

82.3

178.3

LIMESTONE

Limestone, white-light grey, crystalline, abundant shell fragments, corals, echinoids, bryozoa, glauconitic in part.

Strat Unit Name

Murray Group

Strat Unit Description

Limestone, echinoidal, bryzoal, crinoidal; sandstone, calcareous, minor carbonaceous clay and silt.

GIS Code

om-y

178.3

219.5

Thg

LIMESTONE

Limestone, bryzoal, grey-cream, dolomitic in part, minor glauconite.

Strat Unit Name

Gambier Limestone

Strat Unit Description

Limestone, fossiliferous. Open marine shelf.

GIS Code

em-h-g

219.5

236.2

Tye

LIMESTONE

CLAYSTONE

Limestone, light grey-off white, clayey, glauconitic, over claystone, calcareous, glauconitic, shell fragments, light grey-green/grey.

Strat Unit Name

Ettrick Formation

Strat Unit Description

Glauconitic, fossiliferous marl, calcareous clay and mudstone, silt, fine-grained sand.

GIS Code

om-y-e

236.2

557.5

SANDSTONE

CLAYSTONE

Sandstone, fine-coarse grained, loose, quartzose, trace pyrite, interbedded claystone, grey-green, soft, calcareous, fossiliferous, glauconitic, minor coal & lignite.

Strat Unit Name

Renmark Group

Strat Unit Description

Sandstone, carbonaceous sand; silt; clay; lignite. Fluvial lacustrine and swamp environments.

GIS Code

am-r

557.5

725.4

K-mc

SILTSTONE

CLAYSTONE

Siltstone, light grey-grey/green-blue, soft, carbonaceous, glauconitic, lithic fragments, grades to claystone in places, minor interbedded fine grained clayey sandstone.

Strat Unit Name

Coombool Member

Strat Unit Description

Sandstone, interbedded fine to very fine-grained green-grey; grey quartzose and carbonaceous siltstone and grey soft sticky clay.

GIS Code

K----mc

725.4

889.7

K-mm

SILTSTONE

SANDSTONE

Siltstone, grey-dark grey, soft, carbonaceous, trace glauconite, interbedded sandstone, fine-coarse grained, minor claystone, dark grey, soft, shaley.

Strat Unit Name

Merreti Member

Strat Unit Description

Shale and mudstone with interbeds of siltstone and very fine to fine-grained sandstone. Glauconitic, micaceous, carbonaceous.

GIS Code

K----mm

889.7

983.9

K-mp

SANDSTONE

SILTSTONE

Sandstone/sand, medium-coarse grained, gravelly in part, loose-unconsolidated, quartzose, carbonaceous, clayey, minor siltstone & claystone interbeds

Strat Unit Name

Pyap Member

Strat Unit Description

Sandstone, friable; minor interbeds of claystone, and silty argillaceous sandstone. Minor coal associated with glauconitic sandstone.

GIS Code

K----mp

983.9

1188.7

P-u

SHALE

SANDSTONE

Shale, green-black, soft-brittle, fissile, micaceous in part, interbedded sandstone, medium-coarse grained, lithic fragments, white clay matrix.

Strat Unit Name

Urana Formation

Strat Unit Description

Shale; siltstone; sandstone; diamictite; minor conglomerate and carbonaceous intervals.

GIS Code

P----u

1188.7

1379.8

? D

SANDSTONE

SILTSTONE

Interbedded sandstone, fine-coarse grained, white-yellow-brown, quartzose: siltstone, dark red/brown, non-calcareous: claystone, black-red, finely bedded & shaley, rare green-black shale.

Strat Unit Name

Devonian rocks

Strat Unit Description

Undifferentiated Devonian rocks.

GIS Code

D-

Sample Allowed Hazard

Metres From	Metres To	Feet From	Feet To	Core Group	Library Location	Culled	Core Previously Inspected	Sample Record	Sample Returned to Library
0.00	789.40	0.00	2589.90	Cutting	Tonsley	N	Y	N	N
176.80	554.70	580.05	1819.88	Cutting	Tonsley	N	Y	N	N
557.80	850.40	1830.05	2790.03	Cutting	Tonsley	N	Y	N	N
789.40	1371.60	2589.90	4500.00	Cutting	Tonsley	N	Y	Y	N
853.40	1149.10	2799.87	3770.01	Cutting	Tonsley	N	Y	Y	N
880.90	882.90	2890.09	2896.65	Core	Tonsley	N	Y	Y	N
882.90	885.50	2896.65	2905.18	Core	Tonsley	N	Y	N	N
885.50	888.90	2905.18	2916.34	Core	Tonsley	N	Y	N	N
888.90	889.70	2916.34	2918.96	Core	Tonsley	N	Y	N	N
890.00	899.20	2919.95	2950.13	Core	Tonsley	N	Y	N	N
899.20	905.20	2950.13	2969.82	Core	Tonsley	N	Y	N	N
905.20	908.10	2969.82	2979.33	Core	Tonsley	N	Y	N	N
918.00	918.40	3011.81	3013.12	Core	Tonsley	N	Y	N	N
918.40	921.30	3013.12	3022.64	Core	Tonsley	N	Y	Y	N
921.30	923.80	3022.64	3030.84	Core	Tonsley	N	Y	N	N
923.80	924.70	3030.84	3033.79	Core	Tonsley	N	Y	N	N
926.60	935.70	3040.03	3069.88	Core	Tonsley	N	Y	N	N
935.70	937.80	3069.88	3076.77	Core	Tonsley	N	Y	N	N
964.40	967.50	3164.04	3174.21	Core	Tonsley	N	Y	N	N
967.50	969.70	3174.21	3181.43	Core	Tonsley	N	Y	N	N
969.70	971.00	3181.43	3185.70	Core	Tonsley	N	Y	N	N
973.50	974.70	3193.90	3197.83	Core	Tonsley	N	Y	Y	N
974.70	977.80	3197.83	3208.01	Core	Tonsley	N	Y	N	N
977.80	978.90	3208.01	3211.61	Core	Tonsley	N	Y	N	N
982.70	983.30	3224.08	3226.05	Core	Tonsley	N	Y	N	N
1155.20	1370.90	3790.03	4497.70	Cutting	Tonsley	N	Y	N	N
1370.70	1371.50	4497.05	4499.67	Core	Tonsley	N	Y	N	N
1371.50	1373.80	4499.67	4507.22	Core	Tonsley	N	Y	N	N
1373.80	1377.30	4507.22	4518.70	Core	Tonsley	N	Y	Y	N
1377.30	1379.80	4518.70	4526.90	Core	Tonsley	N	Y	Y	Y

Summary Mineral Plots

Shortwave Infrared

Thermal Infrared

Scanned Core Imagery

Sample Number	Depth From	Depth To	Sample Source	Collected By	Date Collected
159697	882.1		Drill core	SOUTH AUSTRALIA. DEPARTMENT OF M	25/01/1989
59349	920.83		Drill core	ALLEY, N.F.	25/01/1989
159696	973.53		Drill core	ALLEY, N.F.	25/01/1989
59347	1373.92		Drill core	ALLEY, N.F.	25/01/1989
1124326	1377.45	1377.55	Drill core	EXTERNAL - REFER CORE INSPECTION	19/09/2006
61194	1378.18		Drill core	ALLEY, N.F.	15/06/1989
59350	1378.43		Drill core	ALLEY, N.F.	15/06/1989
61193	1378.61		Drill core	ALLEY, N.F.	25/01/1989
59351	1378.73		Drill core	ALLEY, N.F.	15/06/1989
59352	1379.46		Drill core	ALLEY, N.F.	15/06/1989
59348	1379.52		Drill core	ALLEY, N.F.	25/01/1989

Document	Document ID	Information Type	Document Details	Reports Database
Envelope	07103/006	Geological Log Ref.	Archer, D.W. Cooltong 1. Well completion report. South Australia. Department of Primary Industries and Resources. Open file Envelope 1988	SAMREF
Envelope	07103/006	Geophysical Log(s)	Archer, D.W. Cooltong 1. Well completion report. South Australia. Department of Primary Industries and Resources. Open file Envelope 1988	SAMREF
Envelope	07103/006	Master Ref.	Archer, D.W. Cooltong 1. Well completion report. South Australia. Department of Primary Industries and Resources. Open file Envelope 1988	SAMREF
Petroleum Docket	27/4/7103	Master Ref.
Envelope	07103/006	Palaeontology Ref.	Archer, D.W. Cooltong 1. Well completion report. South Australia. Department of Primary Industries and Resources. Open file Envelope 1988	SAMREF
