0
4
ns
Kelly bushing to ground surface.
Strat Unit Name
no sample
Strat Unit Description
No sample: lost in drilling, cavity; sea if offshore.
GIS Code
------ns
Strat Unit Name
Woorinen Formation
Strat Unit Description
Sand, pale reddish-brown silty and clayey quartz, pedogenic carbonate. Aeolian.
GIS Code
I---eo
9
47
Tpl
SAND
SANDSTONE
Sand, coarse-pebbly, unconsolidated, finer grained & weakly cemented in top 6m, quartzose, yellowish.
Strat Unit Name
Loxton Sand
Strat Unit Description
Sand, glauconitic, micaceous and shelly gravel; Coarse-grained sand and fine gravel, and calcareous micaceous, medium to coarse-grained sandstone. Shallow marine, beach, aeolian, lacustrine and fluvial.
GIS Code
p----l
47
62
Tmpb
SANDSTONE
? MARL
Sandstone, very fine grained, soft, very clayey (marl?), common mollusc fragments, quartzose, trace pyrite.
Strat Unit Name
Bookpurnong Formation
Strat Unit Description
Marl; silty clay; minor fine-grained sand, glauconitic. Shallow marine.
GIS Code
mp---b
62
201
Ty
LIMESTONE
CALCARENITE
Limestone & calcarenite, fine grained, highly fossiliferous, bryozoa, forams, shell & echinoid fragments, sandy in part, light grey-yellow.
Strat Unit Name
Murray Group
Strat Unit Description
Limestone, echinoidal, bryzoal, crinoidal; sandstone, calcareous, minor carbonaceous clay and silt.
GIS Code
om-y
201
216
Tye
CLAY (UNDIFF. ORIGIN)
SANDSTONE
Clay, very silty, soft, green-grey-brown, calcareous, glauconitic, fine organic material, minor interbedded sandstone, fine-medium grained, pyritic.
Strat Unit Name
Ettrick Formation
Strat Unit Description
Glauconitic, fossiliferous marl, calcareous clay and mudstone, silt, fine-grained sand.
GIS Code
om-y-e
216
524
Tr
SANDSTONE
CLAY (UNDIFF. ORIGIN)
Sandstone, fine-coarse grained, quartzose, unconsolidated, white-light brown, trace pyrite, clay interbeds, brown, lignitic, pyritic, minor beds of lignite.
Strat Unit Name
Renmark Group
Strat Unit Description
Sandstone, carbonaceous sand; silt; clay; lignite. Fluvial lacustrine and swamp environments.
GIS Code
am-r
525
692
K-mc
CLAY (UNDIFF. ORIGIN)
SANDSTONE
Clay & claystone, soft, grey-brown, micaceous, pyritic, lignitic, interbedded sandstone, fine grained, grey-white, glauconitic, carbonaceous, micaceous.
Strat Unit Name
Coombool Member
Strat Unit Description
Sandstone, interbedded fine to very fine-grained green-grey; grey quartzose and carbonaceous siltstone and grey soft sticky clay.
GIS Code
K----mc
692
805
K-mm
CLAY (UNDIFF. ORIGIN)
SANDSTONE
Clay & claystone, soft, grey-brown, micaceous, pyritic, lignitic, rare interbedded fine sandstone, micaceous, carbonaceous.
Strat Unit Name
Merreti Member
Strat Unit Description
Shale and mudstone with interbeds of siltstone and very fine to fine-grained sandstone. Glauconitic, micaceous, carbonaceous.
GIS Code
K----mm
805
914
K-mp
SANDSTONE
CLAYSTONE
Sandstone, medium-very coarse grained, pebbly, white, unconsolidated, quartzose, minor interbedded claystone, glauconitic, pebbly in part.
Strat Unit Name
Pyap Member
Strat Unit Description
Sandstone, friable; minor interbeds of claystone, and silty argillaceous sandstone. Minor coal associated with glauconitic sandstone.
GIS Code
K----mp
914
939
P-u
SANDSTONE
CLAYSTONE
Sandstone, fine-coarse grained, unconsolidated, conglomeratic towards top, & claystone, micaceous, sandy.
Strat Unit Name
Urana Formation
Strat Unit Description
Shale; siltstone; sandstone; diamictite; minor conglomerate and carbonaceous intervals.
GIS Code
P----u
939
944.88
Erk
METAGREYWACKE
Meta-greywacke, very fine-medim grained, hard, green-grey.
Strat Unit Name
Kanmantoo Group
Strat Unit Description
Marine metasandstone, phyllite, schist, gneiss, minor calcsilicate rock and marble.
GIS Code
E-rk
