Qualifications	Organisation	Date	Metres From	Metres To	Insturment Type	Measure Method
Unknown		23/08/2012	2065.63	2094.76

Metres From	Metres To	Type	Value	Unit
2065.63	2065.63	Specific Gravity (density)	2.35	Dimensionless numeric value
2072.03	2072.03	Specific Gravity (density)	2.51	Dimensionless numeric value
2072.87	2072.87	Specific Gravity (density)	2.44	Dimensionless numeric value
2084.91	2084.91	Specific Gravity (density)	1.35	Dimensionless numeric value
2089.71	2089.71	Specific Gravity (density)	2.73	Dimensionless numeric value
2094.76	2094.76	Specific Gravity (density)	2.62	Dimensionless numeric value

Metres From	Metres To	Feet From	Feet To	Core Group	Library Location	Culled	Core Previously Inspected	Sample Record	Sample Returned to Library
158.40	713.20	519.69	2339.90	Cutting	Tonsley	N	Y	N	N
713.20	1246.60	2339.90	4089.90	Cutting	Tonsley	N	Y	N	N
1246.60	1642.80	4089.90	5389.76	Cutting	Tonsley	N	Y	N	N
1374.60	2008.60	4509.84	6589.90	Cutting	Tonsley	N	Y	N	N
1642.80	1825.70	5389.76	5989.83	Cutting	Tonsley	N	Y	N	N
1825.70	2103.10	5989.83	6899.93	Cutting	Tonsley	N	Y	Y	Y
2065.60	2069.20	6776.90	6788.71	Core	Tonsley	N	Y	Y	Y
2069.20	2072.90	6788.71	6800.85	Core	Tonsley	N	Y	Y	Y
2072.90	2075.60	6800.85	6809.71	Core	Tonsley	N	Y	Y	Y
2075.60	2076.90	6809.71	6813.98	Core	Tonsley	N	Y	N	N
2076.90	2080.20	6813.98	6824.80	Core	Tonsley	N	Y	N	N
2080.20	2083.90	6824.80	6836.94	Core	Tonsley	N	Y	N	N
2083.90	2086.90	6836.94	6846.78	Core	Tonsley	N	Y	Y	Y
2086.90	2088.40	6846.78	6851.71	Core	Tonsley	N	Y	N	N
2088.40	2092.10	6851.71	6863.85	Core	Tonsley	N	Y	Y	Y
2092.10	2094.80	6863.85	6872.70	Core	Tonsley	N	Y	Y	Y
2094.80	2098.50	6872.70	6884.84	Core	Tonsley	N	Y	Y	Y

Overview Scalar Plot

Individual Scalar Plots

Scroll down the page to view individual scalar plots Tip: To change the depth display on the overview scaler plot, hover the mouse over the graphs light blue handles, located on the left or right of the overview graph. When over the handle, the mouse pointer displays a double arrow. Clicking on and dragging the handle inwards will alter the depth display in all individual scalar plots below.

Tip: The scalar plot legend is interactive, you can mouse click a legend item to customise the plot display. To change the legend, simply use the mouse to drag and drop legend items in the preferred order. Reordering the legend will effect the order of elements displayed in the graph Tip: To display a sample count of meters, simply hover the mouse pointer over the graph.

Sample Number	Depth From	Depth To	Sample Source	Collected By	Date Collected
2010531	2065.6	2065.78	Drill core	EXTERNAL - REFER CORE INSPECTION	9/04/2013
1834066	2065.63	2065.81	Drill core	EXTERNAL - REFER CORE INSPECTION	16/05/2011
2010532	2071.38	2071.6	Drill core	EXTERNAL - REFER CORE INSPECTION	9/04/2013
1834149	2072.03	2072.26	Drill core	EXTERNAL - REFER CORE INSPECTION	16/05/2011
1834192	2072.87	2073.12	Drill core	EXTERNAL - REFER CORE INSPECTION	16/05/2011
2010515	2072.99	2073.23	Drill core	EXTERNAL - REFER CORE INSPECTION	9/04/2013
1834150	2084.91	2085.14	Drill core	EXTERNAL - REFER CORE INSPECTION	16/05/2011
2010516	2084.95	2085.17	Drill core	EXTERNAL - REFER CORE INSPECTION	9/04/2013
1834151	2089.71	2089.96	Drill core	EXTERNAL - REFER CORE INSPECTION	16/05/2011
2010517	2089.81	2090.07	Drill core	EXTERNAL - REFER CORE INSPECTION	9/04/2013
3396039	2091.67	2092.07	A full face slice of core	EXTERNAL - REFER CORE INSPECTION	6/08/2020
40625	2093.37		Drill core	HIBBURT, J.;GRAVESTOCK, D.I.	15/08/1991
1834152	2094.76	2095.04	Drill core	EXTERNAL - REFER CORE INSPECTION	16/05/2011
2010518	2094.8	2095.05	Drill core	EXTERNAL - REFER CORE INSPECTION	9/04/2013
3396040	2096.36	2096.71	A full face slice of core	EXTERNAL - REFER CORE INSPECTION	6/08/2020
