	Qualifications	Organisation	Date	Metres From	Metres To
Select	Geologist	Department for Energy and Mining	1/06/2020	0	210.75

Metres From	Metres To	Feet From	Feet To	Core Group	Library Location	Culled	Core Previously Inspected	Sample Record	Sample Returned to Library
15.00	20.00	49.21	65.62	Core	Tonsley	N	Y	N	N
20.00	25.00	65.62	82.02	Core	Tonsley	N	Y	N	N
25.00	30.00	82.02	98.43	Core	Tonsley	N	Y	N	N
30.00	35.00	98.43	114.83	Core	Tonsley	N	Y	N	N
35.00	40.00	114.83	131.23	Core	Tonsley	N	Y	Y	Y
40.00	47.00	131.23	154.20	Core	Tonsley	N	Y	Y	N
47.00	54.00	154.20	177.17	Core	Tonsley	N	Y	Y	N
54.00	61.00	177.17	200.13	Core	Tonsley	N	Y	Y	Y
61.00	68.00	200.13	223.10	Core	Tonsley	N	Y	Y	Y
68.00	75.00	223.10	246.06	Core	Tonsley	N	Y	Y	Y
75.00	82.00	246.06	269.03	Core	Tonsley	N	Y	N	N
82.00	89.00	269.03	291.99	Core	Tonsley	N	Y	Y	Y
89.00	96.00	291.99	314.96	Core	Tonsley	N	Y	N	N
96.00	103.00	314.96	337.93	Core	Tonsley	N	Y	N	N
103.00	110.00	337.93	360.89	Core	Tonsley	N	Y	Y	Y
110.00	117.00	360.89	383.86	Core	Tonsley	N	Y	Y	N
117.00	124.00	383.86	406.82	Core	Tonsley	N	Y	Y	N
124.00	131.00	406.82	429.79	Core	Tonsley	N	Y	N	N
131.00	138.00	429.79	452.76	Core	Tonsley	N	Y	N	N
138.00	145.00	452.76	475.72	Core	Tonsley	N	Y	Y	Y
145.00	152.00	475.72	498.69	Core	Tonsley	N	Y	N	N
152.00	159.00	498.69	521.65	Core	Tonsley	N	Y	N	N
159.00	166.00	521.65	544.62	Core	Tonsley	N	Y	Y	Y
166.00	173.00	544.62	567.59	Core	Tonsley	N	Y	Y	N
173.00	180.00	567.59	590.55	Core	Tonsley	N	Y	Y	Y
180.00	187.00	590.55	613.52	Core	Tonsley	N	Y	N	N
187.00	194.00	613.52	636.48	Core	Tonsley	N	Y	Y	N
194.00	201.00	636.48	659.45	Core	Tonsley	N	Y	N	N
201.00	208.00	659.45	682.41	Core	Tonsley	N	Y	Y	Y
208.00	210.75	682.41	691.44	Core	Tonsley	N	Y	Y	N

Overview Scalar Plot

Individual Scalar Plots

Scroll down the page to view individual scalar plots Tip: To change the depth display on the overview scaler plot, hover the mouse over the graphs light blue handles, located on the left or right of the overview graph. When over the handle, the mouse pointer displays a double arrow. Clicking on and dragging the handle inwards will alter the depth display in all individual scalar plots below.

Tip: The scalar plot legend is interactive, you can mouse click a legend item to customise the plot display. To change the legend, simply use the mouse to drag and drop legend items in the preferred order. Reordering the legend will effect the order of elements displayed in the graph Tip: To display a sample count of meters, simply hover the mouse pointer over the graph.

Sample Number	Depth From	Depth To	Sample Source	Collected By	Date Collected
38538	36		Drill core	MORRIS, B.J.	25/07/1975
38643	36		Drill core	MORRIS, B.J.	25/07/1975
114312	47	48	Drill core	SDM
38539	55		Drill core	MORRIS, B.J.	25/07/1975
38644	55		Drill core	MORRIS, B.J.	25/07/1975
137661	59.8		Drill core	RICHARDS, N.C.	1/11/1980
38648	60		Drill core	MORRIS, B.J.	25/07/1975
38543	60		Drill core	MORRIS, B.J.	25/07/1975
2916911	63.3	63.9	Drill core	EXTERNAL - REFER CORE INSPECTION	9/12/2019
38540	65		Drill core	MORRIS, B.J.	25/07/1975
38645	65		Drill core	MORRIS, B.J.	25/07/1975
38541	70		Drill core	MORRIS, B.J.	25/07/1975
38646	70		Drill core	MORRIS, B.J.	25/07/1975
137665	71.2		Drill core	RICHARDS, N.C.	1/11/1980
2916912	84.2	84.4	Drill core	EXTERNAL - REFER CORE INSPECTION	9/12/2019
38542	106		Drill core	MORRIS, B.J.	25/07/1975
38647	106		Drill core	MORRIS, B.J.	25/07/1975
127484	110		Drill core	MCDONALD, G.D.	1/11/1992
38519	113		Drill core	THOMSON, B.P.	1/12/1975
38520	115		Drill core	THOMSON, B.P.	1/12/1975
137668	115.4		Drill core	RICHARDS, N.C.	1/11/1980
38521	117		Drill core	THOMSON, B.P.	1/12/1975
127866	121.3		Drill core	MCDONALD, G.D.	1/11/1992
127473	143.5		Drill core	MCDONALD, G.D.	1/11/1992
2916913	144.41	144.43	Drill core	EXTERNAL - REFER CORE INSPECTION	9/12/2019
38522	160		Drill core	THOMSON, B.P.	1/12/1975
38649	161		Drill core	MORRIS, B.J.	25/07/1975
38544	161		Drill core	MORRIS, B.J.	25/07/1975
127865	171.75		Drill core	MCDONALD, G.D.	1/11/1992
2916914	173.1	173.2	Drill core	EXTERNAL - REFER CORE INSPECTION	9/12/2019
127493	193.5		Drill core	MCDONALD, G.D.	1/11/1992
2916915	204.1	204.2	Drill core	EXTERNAL - REFER CORE INSPECTION	9/12/2019
114311	209	210	Drill core	SDM

Document	Document ID	Information Type	Document Details	Reports Database
Report Book	77/00051	Geochemistry Ref.	Morris, B.J. Porphyry style copper/molybdenum mineralization at Anabama Hill and the Cronje Dam copper prospect. South Australia. Department of Mines. Report Book 1981	SAMREF
Report Book	77/00051	Geochronology Ref.	Morris, B.J. Porphyry style copper/molybdenum mineralization at Anabama Hill and the Cronje Dam copper prospect. South Australia. Department of Mines. Report Book 1981	SAMREF
Report Book	77/00051	Geological Log Ref.	Morris, B.J. Porphyry style copper/molybdenum mineralization at Anabama Hill and the Cronje Dam copper prospect. South Australia. Department of Mines. Report Book 1981	SAMREF
Report Book	77/00051	Geophysical Log(s)	Morris, B.J. Porphyry style copper/molybdenum mineralization at Anabama Hill and the Cronje Dam copper prospect. South Australia. Department of Mines. Report Book 1981	SAMREF
Report Book	77/00051	Master Ref.	Morris, B.J. Porphyry style copper/molybdenum mineralization at Anabama Hill and the Cronje Dam copper prospect. South Australia. Department of Mines. Report Book 1981	SAMREF
Report Book	77/00051	Petrology Ref.	Morris, B.J. Porphyry style copper/molybdenum mineralization at Anabama Hill and the Cronje Dam copper prospect. South Australia. Department of Mines. Report Book 1981	SAMREF
